Basler L304kc User Manual

Camera Interface
BASLER L304
kc 2-9
Draft
2.5.4 Video Data
Table 2-3 lists the assignment of pixel data bits to the input ports on the transmitter in the camera
and the corresponding output pins on the receiver in the frame grabber. These bit assignments
comply with the Camera Link standard. As shown in the table, the bit assignments for pixel data
vary depending on the output mode of the camera. The available output modes are explained in
more detail in Section 2.5.5.
Table 2-3 also shows the assignment for the line valid bit, the data valid bit and the pixel clock.
These assignments are constant for all output modes.
1
See pages 2-10 through 2-12 for more detailed information about how pixel data is transmitted
in this mode.
2
See pages 2-13 through 2-15 for more detailed information about how pixel data is transmitted
in this mode.
Port Camera
Frame
Grabber
3 Tap 8 Bit
Output Mode
1
2 Tap 10 Bit
Output Mode
2
2 Tap 8 Bit
Output Mode
2
Port A0 TxIN0 RxOUT0 Red Pixel Bit 0 Pixel A Bit 0 Pixel A Bit 0
Port A1 TxIN1
RxOUT1 Red Pixel Bit 1 Pixel A Bit 1 Pixel A Bit 1
Port A2 TxIN2
RxOUT2 Red Pixel Bit 2 Pixel A Bit 2 Pixel A Bit 2
Port A3 TxIN3
RxOUT3 Red Pixel Bit 3 Pixel A Bit 3 Pixel A Bit 3
Port A4 TxIN4
RxOUT4 Red Pixel Bit 4 Pixel A Bit 4 Pixel A Bit 4
Port A5 TxIN6
RxOUT6 Red Pixel Bit 5 Pixel A Bit 5 Pixel A Bit 5
Port A6 TxIN27
RxOUT27 Red Pixel Bit 6 Pixel A Bit 6 Pixel A Bit 6
Port A7 TxIN5
RxOUT5 Red Pixel Bit 7 (MSB) Pixel A Bit 7 Pixel A Bit 7 (MSB)
Port B0 TxIN7
RxOUT7 Green Pixel Bit 0 Pixel A Bit 8 Pixel B Bit 0
Port B1 TxIN8
RxOUT8 Green Pixel Bit 1 Pixel A Bit 9 (MSB) Pixel B Bit 1
Port B2 TxIN9
RxOUT9 Green Pixel Bit 2 Not Used Pixel B Bit 2
Port B3 TxIN12
RxOUT12 Green Pixel Bit 3 Not Used Pixel B Bit 3
Port B4 TxIN13
RxOUT13 Green Pixel Bit 4 Pixel B Bit 8 Pixel B Bit 4
Port B5 TxIN14
RxOUT14 Green Pixel Bit 5 Pixel B Bit 9 (MSB) Pixel B Bit 5
Port B6 TxIN10
RxOUT10 Green Pixel Bit 6 Not Used Pixel B Bit 6
Port B7 TxIN11
RxOUT11 Green Pixel Bit 7 (MSB) Not Used Pixel B Bit 7 (MSB)
Port C0 TxIN15
RxOUT15 Blue Pixel Bit 0 Pixel B Bit 0 Not Used
Port C1 TxIN18
RxOUT18 Blue Pixel Bit 1 Pixel B Bit 1 Not Used
Port C2 TxIN19
RxOUT19 Blue Pixel Bit 2 Pixel B Bit 2 Not Used
Port C3 TxIN20
RxOUT20 Blue Pixel Bit 3 Pixel B Bit 3 Not Used
Port C4 TxIN21
RxOUT21 Blue Pixel Bit 4 Pixel B Bit 4 Not Used
Port C5 TxIN22
RxOUT22 Blue Pixel Bit 5 Pixel B Bit 5 Not Used
Port C6 TxIN16
RxOUT16 Blue Pixel Bit 6 Pixel B Bit 6 Not Used
Port C7 TxIN17
RxOUT17 Blue Pixel Bit 7 (MSB) Pixel B Bit 7 Not Used
DVAL TxIN26
RxOUT26 Data Valid
LVAL TxIN24
RxOUT24 Line Valid
Not Used TxIN23
RxOUT23 Connected to Ground
Not Used TxIN25
RxOUT25 Connected to Ground.
CL PClk TxCLKIn
RxCLKOut Pixel Clock
Table 2-3: Bit Assignments
