Configuring the Camera
4-32 BASLER L304kc
Draft
Shading Mode CSR
Shading Value Generate CSR
Register Base Address: 0x2000
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Mode Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field sets the shading correction mode:
0x00 = Shading correction disabled
0x01 = Enable DSNU shading correction only
0x02 = Enable PRNU shading correction only
0x03 = Enable DSNU and PRNU shading correction
See Section 3.10.1 for more information about shading correction.
Register Base Address: 0x2100
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x02 = The generation process failed
0x80 = A value in the register is set out of range
Field Name: Generate Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field will begin the routine that generates a set of shading
correction values:
0x00 = No generation.
0x01 = Generate DSNU correction values.
0x02 = Generate PRNU correction values and do not use DSNU correction
during generation.
0x03 = Generate PRNU correction values and use DSNU correction during
generation.
See Section 3.10.1 for more information about shading correction.
