3.2.2 Sensor LEDs
Designation Illuminated Flashing
OUT2 Yellow Switching output 2 active. Signal reserve of the detected
object is close to the detection
limit.
OUT1 Yellow Switching output 1 active. Signal reserve of the detected
object is close to the detection
limit.
ALARM Red Sensor starts up.
Measured value that is on a
switching output is invalid.
Sensor is parameterized via a
web interface.
Signal reserve of the detected
object is close to the detection
limit.
POWERLINK Green The sensor is ready for opera-
tion, but no active USB connec-
tion present
.As soon as USB connection is
active, the LED switches off.
Short circuit at switching out-
put1 or 2.
Blue USB connection active. Data packets are being received
via USB.
Yellow - Modbus package received.
Special modes:
OUT1, OUT2,
ALARM,
POWERLINK
Yellow,
red,
violet
All LEDs flash twice, then a
longer pause. Indicates a sensor
error.
