Baumer Web interface operation | 9
V2 | OX100 Operating Manual 61
Behaviour of the switching output in point mode
High
Low
Level
Hysteresis
Switching point P1
Active low level
Ill.29: Behaviour of the switching output in point mode (positive hysteresis)
High
Low
Level
Hysteresis
Switching point P1
Active low level
Ill.30: Behaviour of the switching output in point mode (negative hysteresis)
Behaviour of the switching output in window mode
High
Low
Level
Hysteresis
Switching point P2
Active high level
Switching point P1
Hysteresis
Window
Ill.31: Behaviour of the switching output in window mode (positive hysteresis)
