3 Description
3.1 Sensor
3.1.1 Structure
1
2
3
4
5
Ill.2: Structure
1 Electrical connection 12-pin M12,A-en-
coding,male
2 USB-C connection with blind plug
3 Sensor LEDs 4 Front panel
5 Mounting holes
