8.2.2 Menu bar
The menu bar allows the navigation among the modes of the web interface. The currently se-
lected menu item is highlighted by a blue ribbon and blue text.
Monitoring
n
Display of measured data.
n
No parameter change enabled.
Parametrization
n
Sensor parameterization.
n
Access to this mode may protected by password as an option.
n
In parameterization mode, the alarm output is set to high.
− Global Parametrization
n
Initial settings of the signal chain (particularly camera):
▪ Optimisation of data collection.
▪ Optimisation of the field of view.
− Measurement Tools
Parametrization
n
Selection and setup of the smart functions integrated into the
sensor.
− Outputs Parametriza-
tion
n
Allocation of the measured values to the switching outputs.
n
Setting the switching windows and switching points.
− Save Parameter-Setups
n
Storage of the the set parameters as a parameter setup in the
sensor (maximum 32 setups) or externally.
n
External storage is in the .json format. The JSON file can be
transferred to sensors with identical type code (measurement
range and interface).
n
The parameter setups can each be renamed separately as
well as imported/exported.
n
Alternatively, you can import/export the entire parameter
setup.
n
A single file contains all sensor parameters except the inter-
face-relevant parameter.
n
Interface-relevant parameters are also saved when saving the
entire parameter setup block. When importing, you can select
whether these are imported.
Device Configuration
n
Setting the interface-specific properties (Ethernet configura-
tion, active process interfaces).
Condition Monitoring
n
Display of diagnostic data, such as operating time, tempera-
ture and operating voltage.
