11 Troubleshooting
CAUTION
Release of dangerous laser radiation when the sensor is defective.
Use of the sensor with a fractured front panel or loose/exposed laser optics can release danger-
ous laser radiation.
a) In case of a fractured front panel or loose/exposed laser optics disconnect the laser from the
power immediately.
b) Have the sensor checked by an authorised person (specialist). Do not operate the sensor
until that time.
11.1 Resetting the sensor to the factory settings
Resetting the sensor to the factory settings is necessary, for instance, if the IP address of the
sensor was changed and you can no longer connect to the sensor. Proceed as follows:
Instruction:
a) Disconnect the sensor from the power supply.
b) Connect OUT1 to OUT2 (see Pin assignment [}28]).
c) Connect the sensor to the power supply.
d) Connect to sensor as described in Connecting the sensor to the PC [}29]. Apply the default
settings.
ü A special page opens.
e) Select Factory Default and wait for the response from the sensor.
f) Separate OUT1 and OUT2.
g) Select Restart sensor.
Result:
ü The sensor is now reset to the factory settings.
11.2 Return and repair
In case of complaints, please contact the relevant sales company.
11.3 Accessories
You can find accessories at the website at:
https://www.baumer.com
