Baumer Electrical installation | 6
V2 | OX100 Operating Manual 27
6 Electrical installation
6.1 General instructions for electric installation
NOTICE
Device damage due to faulty power supply.
The device can be damaged due to faulty power supply.
a) Operate the device only with protected low voltage and safe electrical isolation of protection
class III.
NOTICE
Device damage or unintended operation due to work on live parts.
Any wiring work on live parts may lead to unintentional operation.
a) Prior to performing any wiring work disconnect power supply.
b) Only connect or disconnect any terminals when not live.
NOTICE
IP65 protection is no longer present after removing the protective plug.
Remove the protective plug for the shortest time possible and only in a clean ambiance.
n
The sensor's USB port is only for temporary data transmission, e.g. parameterization or
trouble shooting. It is not intended as host interface for permanent use at the installation in
industrial environments. Power supply always via the 12-pin M12 connector.
n
Prerequisites for IP rating:
▪ Cable connection present at the process interface (12-pin M12 connector).
▪ The USB port must be sealed (black cap) during operation. When putting on the black
cap, make sure it is free from soiling (dust or liquids).
