8.2.3 Window Measurement Results
The parameterized measured values appear in window Measurement Results. Display layout
depends on the sensor-configured measurement tools. First, the window is empty but it allows
for display of up to 7 measured values. Clicking one of the fields provides the assigned mea-
sured value in the visualisation area. The current selection is visualized by a blue line or by be-
ing indented. In the webinterface, the measured values come in the order they are transmitted
via the process interfaces.
n
A yellow symbol indicates whether the measured value is as-
signed to one of the switching outputs or the analogue output.
The colour of the symbol does not change regardless whether
the switching output is active or not.
n
See also Mode Outputs Parametrization [}58].
8.2.4 Footer
The footer is found at the bottom of the user interface. The footer is always visible, no matter of
the currently applied mode.
Measurement Rate
n
Display of the current measurement rate (in Hz).
Alarm
n
Status of the alarm output:
▪ Red: Alarm output is active.
Switching Output
n
Status of the switching output:
▪ Yellow: switching output active.
▪ Grey: switching output inactive.
8.2.5 Visualisation area
The measured data is displayed in the visualisation area. The style and structure of the visuali-
sation area depend on the currently active mode of the web interface.
8.2.6 Parametrisation area
In the parametrisation area, depending on the selected menu item within the Parametrization
mode, you can set various parameters (see Mode Global Parametrization [}38], Mode Mea-
surement Tools Parametrization [}54], Mode Outputs Parametrization [}58] and Mode Save
Parameter-Setups [}62]).
