7.3 Set up RS485 interface with Modbus RTU
The sensor supports Modbus RTU and ASCII via RS485 for retrieving measured values and for
parameterization.
Communication via the RS485 interface is a serial master-slave communication, reason why the
serial communication parameters must first be known for all users:
n
Slave address: 1
n
Data bits: 8
n
Number of stop bits: 1 bit
n
Parity: even
n
Baud rate (bps): 19200 (default), to be optionally changed via the web interface
Example: Reading out measured values
Instruction:
a) Stellen Sie die Kommunikationsparameter (s.o.) am Master ein.
b) Read the input register.
Function ID: 04
Address 200: All Measurement values (see chapter Modbus RTU [}18])
Number of registers: 24
Result:
ü You receive the response telegram of the structure described in chapter Modbus RTU
[}18].
INFO
1 Modbus register corresponds to 2 bytes. If the data type of a sensor parameter is wider than a
2 byte Modbus register, the parameter is divided among several Modbus registers. The less sig-
nificant bits are located at the smaller address and the more significant bits at the larger ad-
dress (Little Endian).
