Baumuller b maXX 5500 - EtherCAT

Controller terminals
Instruction handbook b maXX BM5500, BM5600, BM5700
Document No.: 5.13008.10 Baumüller Nürnberg GmbH
196
of 314
7.12
X3 / X4 - fieldbus
connection
EtherCAT
®
Type code BM5500, BM5600, BM5700 with EtherCAT
®
CoE profile:
BM5XXX-XXXX-XXXX-01XX
Type code BM5500, BM5600, BM5700 with EtherCAT
®
SoE profile:
BM5XXX-XXXX-XXXX-07XX
X3
X4
EtherCAT
®
IN
EtherCAT
®
OUT
Number of bus connections 1 IN / 1 OUT
Bus connection RJ 45
Number of parameters Refer to
parameter handbook BM5000
Data width of parameters 16 / 32 Bit
Baud rates 10 / 100 Mbit/s
1: TX+
2: TX-
3: RX+
4: Reserved
5: Reserved
6: RX-
7: Reserved
8: Reserved
X3
X4
