Baumuller BM4400 - Page 247

Troubleshooting and fault correction
Instruction handbook b maXX BM4400, BM4600, BM4700
Document No.: 5.12008.07
247
of 358
9
P0211 Error drive management
P0212 Error data set management
Error No. Meaning Reaction Troubleshooting
160 Timeout communication adjustable Remove the timeout of the Proprog communication
161 Timeout BACI adjustable Remove the timeout of the BACI communication option
module
162 Timeout cyclic communication adjustable Remove the timeout of the Cyclic communication:
163 Timeout service data adjustable
164 Field bus error adjustable Check the field bus communication
165 Controller not synchronous to external signal adjustable Set the Sync offset and/or Sync tolerance
166 Error at brake control IS Check the wiring and the function of the brake
167 No release of holding brake when starting the
drive
IS Check the holding brake
168 No closing of holding brake at stopping of drive adjustable
169 Error holding brake status (cyclic monitoring) adjustable
170 Error holding brake lining adjustable
171 Error initialize holding brake IS Check, if there is a DIO module, if it is in the correct
slot and if it is correctly parameterized (also see
P0883)
172 Error holding brake: holding torque not reached IS Ensure that the torque limits are not set too small
|P1402| < Min (|P1036|, |P1037|, |P1038|)
173 to 175 reserved, not assigned = 0
Error No. Meaning Reaction Troubleshooting
176 EEPROM copy error adjustable Copy the data set once more
177 Write timeout EEPROM adjustable The data in the EEPROM are invalid, please safe all
data sets
178 Checksum error EEPROM IS EEPROM faulty or described faulty
179 No boot data set IS The data in the EEPROM are invalid, please safe all
data records
180 Incompatible software IS
181 There is no data set adjustable
182 Checksum error im PSI module adjustable PSI EEPROM faulty or write faulty
183 PSI is reset adjustable Please save all data records
184 PSI data invalid adjustable The data in the PSI are invalid, please save all data
sets
185 Autotuning tables invalid. adjustable Restart autotuning
186 A/D correction table invalid adjustable Replace the controller cartridge
187 EEPROM is reset IS The data in the EEPROM is reset, please safe all data
records
188 to 191 reserved, not assigned = 0
