07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 11-1
Chapter 11
Chapter 11 Illustrated Parts Breakdown
Overview
This section includes illustrations and parts lists required to identify any
replaceable part in the FLO-GARD 6301 Dual Channel Volumetric Infusion
Pump. Each illustration is keyed to a parts list, which lists each component
shown in the figure by part number and description. The quantity per
assembly is also shown. To obtain replacement parts, contact product service.
The first column shows the figure and item number of each part. The second
column is the Product Service part number. The third column is the
manufacturer’s part number, and the last column is the quantity per assembly.
