11-26 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
Table 11-11 Parts List - Pump Head 2 Base Plate Assembly
Item Svc. Part # Mfg. Part # Description Qty
1 LBRC1008.A S048018 BLOCK, Mounting, Latch Pin-P2 1
2 LBSHZ101.B S048501 BUSHING, Door Hinge 4
3 LPiNS101.A S048447 PIN, Latch 1
4 LPiNS101.E S048453 PIN, Latch Mounting Block 2
5 LPLTC106.A S048017 PLATE, Base-P2 1
6 LXWZ1006.A S048522 WASHER, Latch Roller 1
7 NROLP100.A S048455 Latch Roller 1
8 PGiDM100.D S048486 GUIDE, Tubing, Lower Channel 2
9 PGiDM100.E S048487 GUIDE, Tubing, Lower Channel 3
10 QSWZ1011.A S047933 SENSOR, Tube Misload-2L 1
11 QSWZ1012.A S047934 SENSOR, Tube Misload-2R 1
12 S055623 S055623 DECAL, Channel Right 1
13 0726A1202 07-26-A1-202 LABEL, Slide Clamp Slot 2
14 XBSSF20P.B 4009310081 SCREW, Flat Head, M2X5 2
15 XBSUF30P.C S048963 SCREW, Flat Head, M3X8 1
16 PZETL102.B S050045 TAPE, Conductive, Finger 2
17 PBOX1004.A S048432 Finger Box 1
18 OiCMP32T.G S048895 Washer, M3 6
19 XBPSD30P.K S048940 Screw, Pan Head, M3X8 6
20 BLBRCASSY1 S047945 BLOCK, Mounting Assembly Pump 2 1
To Next Page
