07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 11-5
Illustrated Parts Breakdown Overview
Table 11-3 Parts List - Rear Housing Assembly
Item Svc. Part # Mfg. Part # Description Qty
1 CPWBN104.B F043130001 PCB, ASSEMBLY - Terminal 1
2 CPWBN104.C F043130003 PCB, ASSEMBLY - Backup Audible Alarm 1
3 CPWBN104.A F043130004 PCB, ASSEMBLY - Audible Alarm 1
4 GCABB104.D F051624002 HOUSING, Rear 1
5 GLEGG100.D F044630001 FOOT, Rubber 2
6 LANGQ103.A F044211001 PLATE, Main Grounding 1
7 LANGQ103.B F044220003 PLATE, Vol./Lock Ground 1
8 LANGT103.D F054220002 BRACKET, XFORMER 1
9 PGUMM103.D F044620003 BOOT, Rubber - Main Buzzer 1
10 PGUMM103.E F044620004 BOOT, Rubber - Backup Buzzer 1
11 QCNW1043.B F044140001 GND WIRE, Front Housing 2
12 QCNW1052.B F044140003 GND WIRE, XFORMER 1
13 QCNW1058.A F044140002 GND Wire, Pwr Receptacle 1
14 QCNW1114.A F052140001 HARNESS, Buzzer 1
15 QCNW1118.A 5009415002 CABLE, Flat Ribbon 1
16 QSWP1008.A 5009470002 SWITCH, Panel Lock 1
17 RDENC100.E F059130003 DC Power Supply 1
18 RTRNP100.F 5009462002 AC Transformer, 117V, 60Hz 1
19 RVRC1350.A 2501003200 POT, Volume Control 1
20 XBPBN40P.E 4009310003 SCREW, Pan Head-M4X8 w/ washer assy 7
21 XUPSD30P.B 4009310020 SCREW, Pan Hd-Tapping M3X8 9
22 XUPSD40P.A 4009310021 SCREW, Pan Hd-Tapping M4X8 4
23 XWHSD300.C 4009330001 WASHER, Rubber Foot-M3 4
24 PZETL102.i 3004010009 FILM, Power Trans Insulation 1
25 XEPSD30P.A 4009310018 SCREW, Pan Hd-M3X8 4
