Rear Controls and Indicators
The following items are located on the rear of the pump and are shown in
Figure 2-3.
Item Function
1. IV Pole Clamp Secures the pump to the IV pole.
2. Power Cord Strap Stores power cord during battery operation and pump storage.
3. Audio Speakers For generation of audible alarm and alert tones.
4. Battery Compartment Allows authorized service personnel easy access to the battery, EPROMS, and battery
fuse.
5. Fuse Compartment The power cord cover must be removed to access the fuses.
6. Power Cord Removable only by authorized service personnel.
7. PANEL LOCK Switch Disables all front panel keys, except BACKLIGHT and TOT VOL/STATUS, while the
pump is running without alerts.
8. COMMUNICATIONS
PORT
The communications port contains wiring for a nurse call jack as well as RS-232 serial
communications. See the Technical Specifications listed previously in this section.
9. Volume Knob Adjusts loudness of audible alarm and alert tones. The audible alarm cannot be turned
completely off.
