8 Disassembly/Reassembly
8-22 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
19. Place a 0.3mm, flat-feeler gauge between the motor bottom surface and
the motor end plate. When the flat-feeler gauge cannot be inserted, or the
gap is wider than 0.3mm, loosen the set screws (Figure 11-8 or
Figure 11-13 , item 27) to move the motor. Ensure that the edge of the
flat-feeler gauge is touching the side of the motor shaft. Press the motor
against the plate and tighten the set screws to 5 kgf-cm (4.3 in-lb).
20. Install safety clamp arm cover. Tightening torque for the arm cover
securing screw (Figure 11-7 or Figure 11-12 , item 2) is 1 kgf-cm
(0.9 in-lb). Remove the flat-feeler gauge.
21. Install pump head assembly into case in accordance with “Replacement
of Pump Head Assembly” on page 8-12.
22. Install pump door cover in accordance with “Replacement of Pump Head
Door Cover” on page 8-9.
23. Perform the Operational Checkout procedures in Chapter 10,
“Operational Checkout”.
Spring Retainer Removal
The spring retainer is installed into the slide clamp slot at the factory to
maintain proper tension on the springs within the assembly. It must be
removed prior to use if the Insert Slide Clamp option is enabled.
1. Open the pump door. See Figure 2-2 for the location of the spring
retainer.
2. Press the safety clamp arm cover in until the safety clamp latches open.
3. Using E-ring pliers, insert the tips into the holes in the spring retainer.
4. Gently remove the spring retainer. Keep the removed spring retainer in
case it is needed in the future.
5. Close the pump door to release the latched mechanism.
Spring Retainer Installation
The spring retainer is installed into the slide clamp slot at the factory to
maintain proper tension on the springs within the assembly. If the Insert Slide
Clamp option is not going to be used, the spring retainer should remain in the
assembly during pump use to maintain proper spring tension as well as to help
prevent the ingress of fluids into the mechanism. Instructions for installing the
spring retainer are provided below.
