07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 1-1
Chapter 1
Chapter 1 Introduction
Overview
This manual provides service information for the FLO-GARD 6301 Dual
Channel Volumetric Infusion Pump (product code 2M8064) for qualified
hospital biomedical engineers and service personnel. It is strongly
recommended that you read the pump’s Operator’s Manual (part number
07-19-x1-564) for detailed operating instructions and operator oriented
information, warnings, and cautions.
This chapter contains the following information:
Q “Safety Summary,” 1-2
Q “Warranty Information,” 1-4
Q “Service Information,” 1-4
Q “General Information,” 1-5
The FLO-GARD 6301 Dual Channel Volumetric Infusion Pump is an
electromechanical pump used for the intravenous infusion of fluids at
user-selected rates. The pump contains two linear peristaltic pump heads,
allowing it to simultaneously infuse two different solutions. Each pump head
is independently programmable and permits infusion of primary and
secondary medication programs. The secondary program automatically
switches over to the primary program when secondary infusion is complete
(automatic piggybacking).
The pump operates on standard 115 VAC 60 Hz electrical power, or on its
self-contained rechargeable battery. It is portable and has a panel lock-out
feature to prevent tampering. It is designed for use with Baxter’s standard
administration sets that contain an “s” as the last character of the code
number, for example, 2C5537s. When infusing solutions through a central
line catheter, sets with a Luer lock adapter should be used. Sets with a
Flashball device are not recommended in these applications.
