07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 11-3
Illustrated Parts Breakdown Overview
Table 11-2 Parts List - Front Housing Assembly (F059990006)
Item Svc. Part # Mfg. Part # Description Qty
1 CPWBN105.D F052130001 DISPLAY PCB ASSEMBLY 1
2 CPWBX105.A F051130002 CPU PCB ASSEMBLY 1
3 GCABA104.B F051624001 HOUSING, Front 1
4 GLEGG100.D F044630001 FOOT, Rubber 2
5 LANGT103.B F042220001 BRACKET, Pump Head 2, Mounting 1
6 LANGT103.C F052220001 BRACKET, Pump Head 1, Mounting 1
7 PGUMM103.G F054630001 SEAL, Rubber, Housing 1
8 PSPAF103.A F044230001 SPACER, Pump Head 2 1
9 PSPAF103.B F054230001 SPACER, Pump Head 1 1
10 PSPAN103.A F049620013 SPACER, Double Locking PCB 4
11 QCNW1043.B F044140001 WIRE, Grounding 1
12 XBPBN30P.A 4009310001 SCREW, Pan Head, M3X6 1
13 XBPBN40P.E 4009310003 SCREW, Pan Head, M4X8 3
14 XBPSD30P.G 4009310038 SCREW, Pump Head, M3X6 2
15 XUPSD30P.B 4009310020 SCREW, Pan Hd-Tapping, M3X8 12
16 XWHSD300.C 4009330001 WASHER, Rubber Foot M3 4
17 XEPSD30P.A 4009310018 SCREW, Pan Head, M3X8 4
18 UBATL100.A 5009480002S BATTERY, Lithium 1
19 PSEL1008.A 3004090005 SEAL, Dust, LCD 1
