11-30 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
Table 11-13 Parts List - Pump 2 Base Plate Assembly with Pump Mechanism
Item Svc. Part # Mfg. Part # Description Qty
1 CCRA1006.A S047875 Clamp, Safety Slide Assy 2 1
2 LBRC1006.A S048426 Retainer, Motor Spring 1
3 LBSHZ101.D S048497 Stopper, Cam 1
4 LPLTM104.D S048488 Wheel, Encoder 1
5 LPLTP104.A S048484 Finger, #1,2,7,8 4
6 LPLTP104.B S048485 Finger #3,4,5,6 4
7 MCAMP100.A S048483 Eccentric Cam 8
8 MJNTM100.B S048454 Coupling, Motor 1
9 MSPRD102.A S048471 SPRING, Motor 2
10 NBRGY100.B S048511 BEARING, Pumping Finger 9
11 NBRGY100.C S048512 Bearing, Finger Box 1
12 NSFTD103.A S048433 SHAFT, Finger 1
13 OiCMP32T.F S048894 Washer, Optocoupler, PCB 2
14 OiCMP32T.G S048895 Washer, M3 4
15 PBOX1005.A S048431 COVER, Finger Box 1
16 PCOVP101.B S048427 Cover, Encoder Wheel 1
17 PSPAB102.A S048496 Spacer, Encoder Wheel 1
18 CPBWN105.B S047876 PCB, ASSEMBLY-Optocoupler 1
19 V4PGF352.A S048016 Optocoupler 1
20 RMOTP100.B S048510 Stepping Motor 1
21 XBPSD30P.D 4009310005 SCREW, Pan Head, M3X6 1
22 XBPSD30P.U S048947 Screw, Pan Head, M3X55 4
23 XJPSF20P.A S048955 Screw, Pan Head, M2X6 4
24 XWSSD200.A S048879 Washer, Spring, Optocoupler PCB 2
25 XWSSD300.B S048899 Washer, M3 4
26 XXXSP30L.A S048876 Screw, M3X3 2
27 XXXSP30L.B S048890 SCREW, Set, M3X4 4
To Next Page
