07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 8-3
Removal/Replacement Procedures Preparation for Maintenance
5. Record the contents of the alarm log by pressing the SILENCE and TOT
VOL/STATUS
keys simultaneously then, within one second, press the
CLEAR TOT VOL key to display the rest of the failure codes.
Torque Specifications
The following table provides torque values for the hardware that requires
them.
Table 8-1 Torque Specifications
Component Secured Item No. in Figure Torque Specification
Rear housing to front housing, body
Item 6 in Figure 11-4 9 kgf-cm (7.8 in-lbs)
Rear housing to front housing, handle
Item 40 in Figure 11-4 9 kgf-cm (7.8 in-lbs)
PCBs/hardware to front housing
Item 15 in Figure 11-2 7 kgf-cm (6.1 in-lbs)
Front panel film ground screw
Item 12 in Figure 11-2 3 kgf-cm (2.6 in-lbs)
Door cover to pump head assembly
Item 28 in Figure 11-5 4 kgf-cm (3.5 in-lbs)
Pump head assy 1 and 2 to front
housing
Item 5 in Figure 11-1
Item 7 in Figure 11-1
9 kgf-cm (7.8 in-lbs)
9 kgf-cm (7.8 in-lbs)
Upstream occlusion sensor
Item 16 in Figure 11-7 , Figure 11-12
Item 6 in Figure 11-12 , Figure 11-7
3 kgf-cm (2.6 in-lbs)
1.5 kgf-cm (1.3 in-lbs)
Downstream occlusion sensor
Item 16 in Figure 11-7 , Figure 11-12
Item 6 in Figure 11-12 , Figure 11-7
3 kgf-cm (2.6 in-lbs)
1.5 kgf-cm (1.3 in-lbs)
Air sensor
Item 16 in Figure 11-7
Item 16 in Figure 11-12
2 kgf-cm (1.7 in-lbs)
2 kgf-cm (1.7 in-lbs)
Door latch pin
Item 15 in Figure 11-6 , Figure 11-11 7 kgf-cm (6.1 in-lbs)
Pump motor
Item 22 in Figure 11-8 , Figure 11-13
Item 27 in Figure 11-8 , Figure 11-13
Item 30 in Figure 11-9 , Figure 11-14
6 kgf-cm (5.2 in-lbs)
5 kgf-cm (4.3 in-lbs)
6 kgf-cm (5.2 in-lbs)
Safety slide clamp assembly
Items 28 and 41 in Figure 11-8 ,
Figure 11-13
Item 19 in Figure 11-6 , Figure 11-11
Item 2 in Figure 11-7 , Figure 11-12
Item 35 in Figure 11-9 , Figure 11-14
6 kgf-cm (5.2 in-lbs)
6 kgf-cm (5.2 in-lbs)
1 kgf-cm (0.9 in-lbs)
3 kgf-cm (2.6 in-lbs)
Back plate
Items 26 and 27 in Figure 11-5
Items 26 and 27 in Figure 11-10
6 kgf-cm (5.2 in-lbs)
6 kgf-cm (5.2 in-lbs)
Main battery
Item 26 in Figure 11-4 9 kgf-cm (7.8 in-lbs)
