11-10 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
Table 11-5 Parts List - Pump Head 1 Door Assembly (F059120016)
Item Svc. Part # Mfg. Part # Description Qty
1 F059120016 F059120016 PUMP HEAD 1 DOOR ASSEMBLY 1
2 CHNDP100.G S047879 LATCH, Door Assy-P1 1
3 JHNDP100.C S048630 LATCH, Door-P1 1
4 LPLTP106.A S048440 PLATE, Door Latch Label 1
5 LXRZ1003.A S048882 E-RING, Door Latch 1
6 MSPRC101.D S048500 SPRING, Door Latch 1
7 OiCMP32T.H S048896 WASHER, M4, 0.8T 1
8 OiCMP32T.L S048897 WASHER, M4.2, 0.1x6 2
9 PMAGT100.B S048498 MAGNET, Door Latch 1
10 TLABH109.A 07-26-06-029 LABEL, Push 1
11 S050052 S050052 DOOR, PUMP HEAD-P1 1
12 LBSHZ101.A S048489 BUMPER, Door 2
13 LBSHZ101.C S048502 BUSHING, Door Latch 1
14 LPiNS101.C S047417 PIN, Door Hinge 2
15 LPLTM106.A S048445 PLATE, Safety Clamp (1.2mm thickness) 1
16 LPLTM106.C S048644 COVER, Back Plate-P1 1
17 S048493 S048493 PLATE, BACK 1
18 MSPRC101.C S048499 SPRING, Back Plate 5
19 PAJS1002.A S048494 STOP, Occlusion Detector 2
20 PCUSG101.A S048504 BUMPER, Door 4
21 PZETE100.C S048506 FILM, Plate Insulation 1
22 072626930 072626930 LABEL, Warning FG6X01 Pump 1
23 TLABZ110.G S048657 LABEL, Tube Loading A, P1 1
24 TLABZ110.H S048658 LABEL, Tube Loading B, P1 1
25 XBPSD20P.C S048933 SCREW, Pan Head , M2X8 w/ washer assy 2
26 XBSUZ30P.A S048987 SCREW, Flat Head, M3X6 7
27 XBSUZ30P.F S048966 SCREW, Flat Head, M3X10 1
28 XBSUF30P.A 4009310014 SCREW, Flat Head, M3X12 5
To Next Page
