07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 7-11
Troubleshooting Failure Identification Code Troubleshooting Table
Failure Identification Code Troubleshooting Table
Use Table 7-3 to determine the corrective action necessary to resolve failure
codes. The causes of each failure code are listed in the order in which they are
most likely to occur. Perform the corrective action items in the order in which
they are listed and retest the pump after each action. All replacement
procedures are contained in Chapter 9, “Calibration”.
There are two types of Failure Identification Codes: Alarm (codes 1-19) and
Failure (codes 20 and above). Alarm codes report malfunctions generally
correctable by the operator. Failure codes may require servicing of the pump.
A code of 0 indicates that less than 10 alarms/failures have occurred since the
log was cleared. The time and date are also 0.
Table 7-3 Failure Identification Codes
Code Cause Checks Corrective Action
0 No alarms or failures. No action necessary.
1 Air bubble detected in a Run
mode.
Check for air in tubing. Ensure set
is correct type and is properly
loaded. Ensure set tubing is not
scratched or deformed.
Expel air in tubing. Replace or
reposition set when tubing is
flattened or scratched. Clean air
sensor in accordance with Chapter
6, “Routine Maintenance” when
dirty.
Perform “Automatic Test Mode 2:
Calibration Mode 2” on page 9-16
steps 2 through 6.
When values are not within
specification, recalibrate or
replace the air sensor.
2
3
Downstream occlusion was
detected.
Check for scratched or deformed
tubing. Verify that solution and
ambient temperatures are between
60° and 100° F (15.5° and 37.7°
C). Ensure set is correct type and
is properly loaded. Check for
spilled solution in sensor region.
Remove downstream occlusion
and reposition the tubing. Clean
occlusion sensors in accordance
with “Cleaning” on page 6-1 when
dirty. Raise or lower temperatures
if necessary.
Perform “Automatic Test Mode 1:
Calibration Mode 1” on page 9-14,
steps 1 through 9.
Perform “Safety Slide Clamp
Mechanical Calibration” on page
9-4.
