5 Modifying the Configuration Option Settings
5-2 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
Modifying the Configuration Option Settings
1. Turn off the device.
2. While pressing either of the STOP keys and PANEL LOCK switch,
press either of the
ON-OFF/CHARGE keys. The following occurs:
2.1 The MODIFY CONFIG message appears in the Pump 1
Message Display.
Note: When the message LOCKED OUT is displayed, the configuration option set-
tings can be changed only via computer control. See the Programmer’s Man-
ual for additional information.
2.2 The parameter descriptor appears in the first line of the Pump 2
Message Display when the
NEXT or SEC START key is
pressed.
2.3 The current parameter setting appears in the second line of the
Pump 2 Message Display.
2.4 The programming displays are blank.
3. Press the NEXT or SEC START key to advance to the desired parameter.
The parameters appear in the order shown in Table 5-1.
4. To change the settings, enter the desired value on the front panel. The
selected numeric value is displayed in the Pump 2 Primary Rate display
until the value is locked in by the
PRI START key, or the next parameter
is displayed by pressing the
NEXT or SEC START key.
Note: The alarm log for the pump can be cleared via the configuration option. See
Table 5-1.
5. To lock in the selected value, press the PRI START key. The selected
value is then displayed in the Pump 2 Message Display. To move on to
the next parameter, press the
NEXT key or SEC START key.
6. To exit, press the same ON-OFF/CHARGE key pressed in step 2.
Table 5-1 Configurable Settings
Parameter Description Setting Options
Factory
Settings
1. Alarm Log: Clear alarm/failure codes of Pump 1 or Pump 2. Select 1
or 2 to clear the corresponding pump’s alarm log.
N/A N/A
