07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL D-1
Appendix D
Multiple Key Combinations A ppendix D
The following multiple key combinations can be used to initiate sequences on
the pump. See the appropriate sections for details regarding the proper use of
these combinations. An example of the standard convention used in this table
is given below.
Key combination:
LOCK + STOP + ON-OFF/CHARGE
Action: Press and hold the LOCK key, while simultaneously pressing the
STOP and ON-OFF/CHARGE key, then release all of the keys.
Table D-1 Multiple Key Combinations
Sequence Key Combination Section
Alarm Log (Failure
identification codes)
SILENCE + TOT VOL/STATUS
Press CLR TOT VOL within 3 seconds. The
display scrolls backwards through the alarm
codes and automatically exit at the end.
“Failure Identification Codes” on page 7-7
Flow Check
“.” + TOT VOL STATUS When the keys are
released, the display disappears 10 seconds
later.
Table 5-1
Modify Configuration
LOCK + STOP + ON-OFF/CHARGE “Modifying the Configuration Option
Settings” on page 5-2
View Configuration
TIME + TOT VOL STATUS “Reviewing the Configuration Option
Settings” on page 5-1
Software Version
SILENCE + ON-OFF/CHARGE “Determing the Software Version” on page
7-3
Calibration Test Mode 1
CLR/TOT VOL + 1 + ON-OFF/CHARGE “Automatic Test Mode 1: Calibration Mode
1” on page 9-14
Calibration Test Mode 2
CLR/TOT VOL + 2 + ON-OFF/CHARGE “Automatic Test Mode 2: Calibration Mode
2” on page 9-16
Mfg Test Mode 3
CLR/TOT VOL + 3 + ON-OFF/CHARGE “Automatic Test Mode 3: Manufacturing
Test Mode” on page 7-8
Aging Test Mode 4
CLR/TOT VOL + 4 + ON-OFF/CHARGE “Automatic Test Mode 4: Aging Mode” on
page 7-9
