2 Controls and Indicators
2-2 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
Controls and Indicators
All controls and indicators are described in the following sections and are
shown in Figure 2-1, Figure 2-2, and Figure 2-3. Service personnel should
be familiar with the pump’s features and operation before servicing the
device. When the word “device” is used in this manual, it refers to the entire
FLO-GARD 6301 Dual Channel Volumetric Infusion Pump. Generally, the
word “pump” is used to refer to either Pump 1 or Pump 2.
Each device’s serial number is recorded on a label on the back of the device.
Power Cord 2.75 m (9.0 ft.) long, with hospital grade plug
Leakage Current Typically less than 50 μA (using UL-544 specified test methods)
Power Consumption 50 W
Weight 8.2 kg (18 lbs)
Dimensions 33 cm W x 13 cm D x 29 cm H (13" W x 5.1" D x 11.4" H)
Flow Rate Range Primary program: 1 - 1999 mL/hr in 1 mL/hr increments and
1 - 99.9 mL/hr in 0.1 mL/hr increments. Upper limit can be reduced by
authorized service personnel.
Secondary program: 1 - 999 mL/hr in 1 mL/hr increments and
1 - 99.9 mL/hr in 0.1 mL/hr increments.
VTBI Range 1 - 9999 mL in 1 mL increments and 1 - 99.9 in 0.1 mL increments for both
primary and secondary. Upper limit can be reduced by authorized service
personnel.
Air-in-Line Detection Factory set to NORM that causes the device to alarm on air bubbles
approximately 75 μL or larger. The MIN setting causes the pump to alarm on
bubbles approximately 50 μL or larger.
Fuse 0.5 A Slo-Blo
Nurse Call 9-pin D connector, Pin 1: N/O, Pin 4: N/C, Pin 9: Common
Contact rating: 0.4A at 30 VAC, 2A at 30 VDC resistive load (internal
activation required)
Item Characteristic
