11 Overview
11-28 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
Table 11-12 Pump 2 Base Plate Assembly
Item Svc. Part # Mfg. Part # Description Qty
1 LPLTC106.A S048017 PLATE, Base, P2 1
2 LXBZ1020.A S048918 SCREW, Flat Head, M1.7X6 1
3 MSPR1001.C S048015 SPRING, Downstream Occl. Sensor 1
4 MSPR1002.B S048014 SPRING, Upstream Occl. Sensor 1
5 NSFTZ102.A S048012 ACTUATOR, Occl. Sensor 2
6 OiCMP32T.A S048928 Screw, Pan Head, M1.7X4.5 4
7 OiCMP32T.E S048893 Washer, M1.7 2
8 OiCMP32T.J S048901 Washer, M2 2
9 PCASD100.B S048022 HOUSING, Occl. Sensor 2
10 PCOVP101.C S048436 COVER, Safety Clamp Arm P2 1
11 PZETL102.E S048508 PLATE, Ground, Upstrm. Occl. Sensor 1
12 CCILZ100.A S048011 COIL, Occl. Sensor Assy 2
13 RCORF100.D S048013 Core, Occlusion Sensor 2
14 S048993 S048993 SENSOR, AIR, ASSY-P2 1
15 TLABH109.B 07-26-01-088 LABEL, Safety Clamp 1
16 XBSUF20P.A S048962 SCREWS, Flat Head, M2X10 6
