07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 2-3
Description Controls and Indicators
Front Controls and Indicators
See Figure 2-1 for the locations of the controls and indicators described
below. Items 1 through 9 in Figure 2-1 are associated with Pump 1. The
controls associated with Pump 2 are identical and function in exactly the
same manner. Items 10 through 27 are common to the operation of both
pumps.
Item Function
1. Pump 1 ON-OFF/
CHARGE Key
Turns Pump 1 on and off. The internal battery charger remains on regardless of the
ON-OFF/CHARGE key as long as the pump is plugged in.
2. Pump 1 Door Latch Opens and closes pump door.
3. Pump 1 STOP Key Stops the pump. The STOPPED message appears when the key is pressed. An alert
sounds when the pump is stopped for more than two minutes. Clears all
programming alerts while pump is running.
4. PUMP 1 Key and Indicator Allows the pump to accept keystrokes and other controls common to both pumps
for Pump 1 programming. Yellow LED lights to indicate that Pump 1 is selected.
5. Pump 1 Main Display Shows rate, volume to be infused (VTBI), and total volume infused for primary and
secondary infusion programs.
6. Pump 1 Message Display Shows all Pump 1 messages.
7. Pump 1 ALARM LED Red LED that blinks on and off during a Pump 1 alarm, accompanied by a visual
message display and a repeated sequence of three beeps. An alarm indicates that the
pump requires immediate attention.
8. Pump 1 PUMPING LED Green LED which is constantly lit while Pump 1 is running.
9. Pump 1 ALERT LED Yellow LED which lights during Pump 1 alerts, accompanied by a message display
and a repeated single beep. An alert indicates that the pump needs timely attention.
10. BACKLIGHT key Provides backlighting of the displays when the pump is used in darkened areas. The
key toggles the backlighting on and off. When the device is operating on battery
power, the backlight remains on for 60 seconds and turns off automatically to
conserve battery power.
11. SILENCE Key Temporarily silences an audible alarm or alert for two minutes. All visual alarm or
alert information remains displayed.
12. TOT VOL/STATUS Key Dual-function key. During operation, this key causes total volume delivered and
current settings to display when pressed. It is also used to select a next step in
Review Configuration, Modify Configuration and Programmed Delivery Profile
modes. The word “NEXT” above the key is illuminated when the key is functioning
as a NEXT key.
13. CLEAR TOT VOL Key Resets the total volume delivered to zero when the pump is stopped.
14. TIME Key Enters desired time interval for an infusion during Volume-Time or Rate-Time
programming.
15. PRI RATE Key Allows programming of the primary infusion rate.
