2 Controls and Indicators
2-4 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
16. PRI VTBI Key Allows programming of the primary VTBI.
17. PRI START Key Starts the primary infusion.
18. Plug Icon Green LED, always lit while the pump is plugged in and the battery is charging.
19. MONITOR Legend Lights for at least 2 seconds each time the host computer communicates with the
pump when the pump is in monitor mode.
20. Battery Icon Yellow LED, always lit while the pump is operating on battery power.
21. COMPUTER CONTROL
Legend
Flashes when the pump is initiating communications with a host computer to enter
the computer control mode. It is constantly illuminated when the pump is in
computer control mode.
22. CLR Key Clears any locked in values and programming values currently being entered.
23. SEC START Key Starts the delivery of the secondary solution.
24. SEC VTBI Key Allows programming of the secondary VTBI.
25. SEC RATE Key Allows programming of the secondary infusion rate.
26. Numerical Keypad The numerical values for rate, VTBI, and time are entered with these keys.
27. OPTIONS Key/Legend Enables the device to operate in special modes.
Item Function
