07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 7-9
Troubleshooting Automatic Test Modes
Automatic Test Mode 4: Aging Mode
While the pump is stopped, pressing any numbered key (0 - 6) programs a
preset rate/VTBI combination as follows:
The
RATE/VTBI keys and number keys 7, 8, and 9 are not accepted. Other
specifications are the same as during normal operation.
Automatic Test Mode 5: Display Check Mode
All the LCD segments, LEDs and icons turn on sequentially for a visual check
each time the
STOP key is pressed. At any point in the sequence the SEC
START
key may be pressed to return to the beginning of the sequence.
Automatic Test Mode 6: Time Information Display Mode
In this test mode, the cumulative time values are displayed sequentially each
time the
SEC RATE key is pressed. The test mode first displays the
cumulative Power On time, then the time on battery and finally, the time that
the pump was actually pumping. It should be noted that the first six digits
from the left are the time in hours and the two digits on the right are the time
in minutes. Therefore, the display 0001 02:21 represents 102 hours and 21
minutes.
! WARNING !
This is an Automatic Test Mode for testing the pump during manufacturing only.
This mode must not be used on patients because the rates and VTBI settings
cannot be altered.
Key
Number PRI RATE PRI VTBI SEC RATE SEC VTBI
0
500 3000 999 6000
1
499 0 999 1
2
3 000
3
250 000
4
499 100 0 0
5
1401 100 0 0
6
1999 100 0 0
