Table 11-6 Parts List - Pump 1 Base Plate Assembly
Item Svc. Part # Mfg. Part # Description Qty
1 LBRC1007.A S048626 BLOCK, Mounting, Latch Pin-P1 1
2 LBSHZ101.B S048501 BUSHING, Door Hinge 4
3 LPiNS101.A S048447 PIN, Latch 1
4 LPiNS101.E S048453 PIN, Latch Mounting Block 2
5 LPLTC106.B S048625 PLATE, Base-P1 1
6 LXWZ1006.A S048522 WASHER, Latch Roller 1
7 NROLP100.A S048455 ROLLER, Latch 1
8 PGiDM100.D S048486 GUIDE, Tubing, Lower Channel 2
9 PGiDM100.E S048487 GUIDE, Tubing, Upper Channel 3
10 QSWZ1010.A S047932 SENSOR, Tube Misload-1R 1
11 QSWZ1009.A S047931 SENSOR, Tube Misload-1L 1
12 S055624 S055624 DECAL, Channel Left 1
13 0726A1202 07-26-A1-202 Slide Clamp Slot Label 2
14 XBSSF20P.B 4009310081 SCREW, Flat Head, M2X5 2
15 XBSUF30P.C S048963 SCREW, Flat Head, M3X8 1
16 PZETL102.B S050045 TAPE, Conductive, Finger 2
17 PBOX1004.A S048432 BOX, Finger 1
18 OiCMP32T.G S048895 WASHER, M3 6
19 XBPSD30P.K S048940 SCREW, Pan Head, M3X8 6
20 BLBRCASSY2 S048663 BLOCK, Mounting Assembly, Pump 1 1
