07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 11-31
Illustrated Parts Breakdown Overview
28 XBPSD30P.W 4009310042 Screw, Pan Head, M3X10 w/ Washer Assy 2
29 LANGT103.A S048446 BRACKET, Fixing, Door Sw PCB 1
30 LFiX1011.A S048443 Nut Bar, Finger Box Top 1
31 LFiX1012.A S048444 Nut Bar, Finger Box Bottom 1
32 S048746 S048746 Spacer, Door Sw PCB 1
33 PSPAZ101.A S048490 Retainer, Rubber, Bottom Bearing 1
34 PSPAZ101.B S048491 RETAINER, Rubber, Top Bearing 1
35 PEZTL101.A S048462 Film, Door Switch PCB Insulation 1
36 QPWBN103.B S048492 PCB, Door Open Sw 1
37 QPWBN105.A S048459 PCB, Tube Misload Terminal 1
38 CPWBN105.A S047877 PCB, Flexible Prtntd Crkt Terminal 1
N/A QSWL1003.C S048513 SWITCH, Door Open
40 VRDRV2EY.A S048521 Resistor, 100 Ohms 2
41 XBBSD30P.D 4003910075 SCREW, Binder Head, M3X8 2
42 XBPBN30P.C S048929 SCREW, Pan Head, M3X8 w/ washer assy 2
43 XBPBN40P.F 4009310080 SCREW, Pan Head, M4X6 1
44 XBPSD20P.A S048923 Screw, Pan Head, M2X5 2
45 XBPSD26P.B S048933 SCREW, Pan Head, M2.5X8 1
46 XWHSD200.A S048891 Washer, Door Open Sw PCB Bracket 2
47 XBPSD30P.i S048939 Screw, Pan Head, M3X8 2
The following wire harnesses are not shown:
N/A QCNW1097.A S048473 Harness, Tube Misload Detector 1
N/A QCNW1098.A S048474 Harness, Slide Clamp Sensor 1 & 2 1
N/A QCNW1099.A S048475 Harness, Slide Clamp Sensor 1 & 2 ext. 1
N/A QCNW1100.A S048476 Harness, Optocoupler PCB 1
Table 11-13 Parts List - Pump 2 Base Plate Assembly with Pump Mechanism — continued
Item Svc. Part # Mfg. Part # Description Qty
