07-19-B1-729 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 11-17
Illustrated Parts Breakdown Overview
28 XBPSD30P.W 4009310042 SCREW, Pan Head, M3X10 w/ Washer Assy 2
29 LANGT103.A S048446 BRACKET, Fixing, Door Sw PCB 1
30 LFiX1011.A S048443 NUT BAR, Finger Box Top 1
31 LFiX1012.A S048444 NUT BAR, Finger Box Bottom 1
32 3048746 S048746 SPACER, Door Sw PCB 1
33 PSPAZ101.A S048490 RETAINER, Rubber, Bottom Bearing 1
34 PSPAZ101.B S048491 RETAINER, Rubber, Top Bearing 1
35 PEZTL101.A S048462 FILM, Door Switch PCB Insulation 1
36 QPWBN103.B S048492 PCB, Open Door Sw 1
37 QPWBN105.A S048459 PCB, Tube Misload Terminal 1
38 CPWBN106.A S048624 PCB, Flexible Prtntd Crkt Terminal 1
N/A QSWL1003.C S048513 SWITCH, Door Open 1
40 VRDRV2EY.A S048521 RESISTOR, 100 Ohms 2
41 XBBSD30P.D 4003910075 SCREW, Binder Head, M3X8 2
42 XBPBN30P.C S048929 SCREW, Pan Head, M3X8 2
43 XBPBN40P.F 4009310080 SCREW, Pan Head, M4X6 1
44 XBPSD20P.A S048923 SCREW, Pan Head, M2X5 2
45 XBPSD26P.B S048933 SCREW, Pan Head, M2.5X8 1
46 XWHSD200.A S048891 WASHER, Door Open Sw PCB Bracket 2
47 XBPSD30P.i S048939 SCREW, Pan Head, M3X8 2
The following wire harnesses are not shown:
N/A QCNW1097.A S048473 Harness, Tube Misload Detector 1
N/A QCNW1098.A S048474 Harness, Slide Clamp Sensor 1 & 2 1
N/A QCNW1099.A S048475 Harness, Slide Clamp Sensor 1 & 2 Ext. 1
N/A QCNW1100.A S048476 Harness, Optocoupler PCB 1
Table 11-8 Parts List - Pump Base Plate Assembly — continued
Item Svc. Part # Mfg. Part # Description Qty
To Next Page
