11 Overview
11-20 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
Table 11-9 Parts List - Safety/Slide Clamp Assembly 1
Item Svc. Part # Mfg. Part # Description Qty
1 LCHSM100.E S048636 Upper Housing P1 1
2 LCHSM100.F S048637 Lower Housing P1 1
3 LCHSM100.G S048643 Sensor Housing 1
4 LCHSM100.D S048439 Sensor Housing, SCS2 1
5 LCRA1005.A S048638 Safety Clamp, P1 1
6 LPiNS101.B S048448 Pin, Release 1
7 LPiNS101.F S048986 Pin, Dowel, Slide A 1
8 LPLTP107.B S048639 Motor Holding Plate, P1 1
9 LXRZ1002.A S048881 E-Ring, Shaft 3
10 MARMP100.E S048632 Retainer Arm, Left, P1 1
11 MARMP100.D S048631 Retainer Arm, Right, P1 1
12 MARMP100.F S048642 Arm, Release, P1 1
13 MCAMP100.C S048640 Latch, Safety, P1 1
14 MSLiZ100.A S048425 Slide A 1
15 MSLiZ100.C S048633 Slide Latch P1 1
16 MSPRC101.D S048500 Spring, Door Latch 1
17 MSPRD102.B S048470 Spring, Retainer Arms 2
18 MSPRD102.C S048472 Spring, Slide Shaft 1
19 MSPRD102.D S048469 Spring, Safety Clamp 1
20 MSPRP102.A S048642 Spring, Flat, Slide Shaft 1
21 NSFTD103.B S048449 Shaft, Slide 1
22 LPiND101.D S048450 Pin, Release Pin 1
23 NSFTD103.C S048451 Shaft, Safety Latch 1
24 NSFTD103.D S048452 Shaft, Safety Clamp 1
25 PSLPD100.C S048645 Seal, Safety Clamp, P1 1
26 PZETL101.B S048464 Film, Insulation, PCB 1
27 PZETL102.D 3004010007 FILM, FPC Insulation-P1 1
