7 Failure Identification Code Troubleshooting Table
7-18 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
83 Undefined message type received
from Slave CPU.
Turn pump off and back on. If failure recurs, replace CPU
board.
86 LVDT reading of downstream
occlusion sensor is too low.
Check calibration of downstream
occlusion sensors.
See Failure Identification Code 2.
87 LVDT reading of downstream
occlusion sensor is too high.
Check calibration of upstream
occlusion sensors.
See Failure Identification Code 4.
89 Bank switching control circuit
failure.
Turn pump off and back on. When failure recurs, replace CPU
board.
90 Checksum error of RATE, VTBI
and VI data. Checksum is not 0.
Turn pump off and back on. If failure recurs, replace CPU
board.
91 Checksum error of Programmed
Delivery Profile stored data.
Reset all of PDP. If failure recurs, replace CPU
board.
92 Checksum error of Programmed
Delivery Profile working data.
Reset all of PDP. If failure recurs, replace CPU
board.
93 Write data and read data of
M5M5165 do not agree.
Turn pump off and back on. If failure recurs, replace CPU
board.
94 Configuration option settings
checksum is not 0.
Reset all of the configuration
option settings in accordance with
“Modifying the Configuration
Option Settings” on page 5-2.
Turn pump off and back on.
Check battery voltage in
accordance with “Automatic Test
Mode 1: Calibration Mode 1” on
page 9-14.
If failure recurs, charge or replace
the battery.
Replace CPU board.
95 Checksum error of alarm log data. Turn pump off and back on. Clear
the alarm log via the modify
configuration mode.
If failure recurs, replace CPU
board.
96 Checksum error of ROM code. Turn pump off and back on. If failure recurs, replace CPU
board.
99 Undefined failure code received
from Slave CPU.
Turn pump off and back on. If failure recurs, replace CPU
board.
Table 7-3 Failure Identification Codes — continued
Code Cause Checks Corrective Action
