7 Troubleshooting Chart
7-22 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
The audible alarm volume is not loud
enough.
N/A Turn the VOLUME knob on the rear
of the pump clockwise until the
desired volume is obtained.
Audible alarm is always on. Momentarily disconnect and
reconnect battery.
Check F302 or F15 (ICP301). Check
CN302, CN701, CN751, and CNI/F
for proper connection and continuity.
Charge or replace battery.
Replace Sensor board.
Replace CPU board.
Audible alarm does not sound. Turn pump off and back on. If problem recurs, replace CPU board.
Replace Sensor board.
Replace speaker.
Beep does not sound when a key other
than BACKLIGHT or SILENCE is
pressed when the pump is stopped.
Turn pump off and back on.
Check CN751, CN701, CNI/F1 for
proper connection and continuity.
Repair or replace the connectors.
Replace speaker.
If problem recurs, replace CPU board.
Replace Sensor board.
Optional nurse call is always on. Check CN401 and CNI/F2 for proper
connection and continuity.
Replace CPU board.
Replace Sensor board.
Optional nurse call is always off. Verify that the Nurse Call feature has
been enabled via the addition of a
jumper (R421) on the terminal PCB.
Check CN401 and CNI/F2 for proper
connection and continuity.
Replace CPU board.
Replace Sensor board.
Configuration option cannot be set via
the remote computer.
Note: Computer monitoring and
remote control are available only
when used with user-generated
software applications. See the
FLO-GARD 6301 Programmer’s
Manual for details.
Check the cable connections between
the computer and the pump.
Check that the user-generated
software is properly loaded onto the
computer.
Check CN401 and CNI/F2 for proper
connection and continuity.
Repair connections between computer
and pump.
Restart the program.
Repair or replace connectors as
required.
Replace CPU board.
Replace Sensor board.
Backup buzzer does not activate
during self test.
Check that the buzzer wiring is
connected.
Check for an open fuse on the battery
wire harness.
Plug in connector.
Replace fuse.
Replace backup buzzer.
Table 7-4 Troubleshooting Chart — continued
Symptom Checks Corrective Action
