8 Disassembly/Reassembly
8-20 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
4. Press the safety clamp pin (Figure 11-9 or Figure 11-14 , item 6) to close
the safety clamp.
5. Remove the screw (Figure 11-7 or Figure 11-12 , item 2) on the right
side of the safety clamp arm cover (item 10) and remove the arm cover.
6. Close the pump door.
7. Place the pump head face down and remove the two screws (Figure 11-9
or Figure 11-14 , item 35) to remove the sensor assembly.
8. Remove the two screws (Figure 11-9 or Figure 11-14 , item 30) on the
bottom of the safety/slide clamp assembly to release the motor holding
plate (item 8).
9. Remove the six screws (Figure 11-6 or Figure 11-11 , item 19) on the
finger box and lift the finger and motor assembly off of the base plate.
10. Remove the flexible cable at the back of the slide clamp assembly
(Figure 11-9 or Figure 11-14 , item 29) from the connector on the
terminal board. Be sure to pull the reinforced part so as not to damage
the flexible cable.
11. Remove four screws (Figure 11-8 or Figure 11-13 , items 28 and 41)
securing the safety/slide clamp assembly and remove it from the pump
head base plate.
12. Press the safety clamp pin (Figure 11-9 or Figure 11-14 , item 6) on the
replacement assembly to close the safety clamp.
13. Install the replacement safety/slide clamp assembly into rear of the pump
head base plate and secure with four screws (Figure 11-8 or
Figure 11-13 , items 28 and 41). Make sure safety clamp seal
(Figure 11-9 or Figure 11-14 , item 25) is in place and moves freely side
to side with the safety clamp arm. Tightening torque for the four screws
is 6 kgf-cm (5.2 in-lb).
14. Inspect for a white or yellow dot on the side of the slide clamp assembly
(nearest the middle of the device) and on the FPC terminal PCB (see
Figure 8-2 for location). If a dot is present, proceed to step 15.
