BEECHCRAFT
Debonair C33
Bonanza E33and F33
Section VII
Systems Description
BRAKES
The brakes
on the main landing gear wheels are operated
by applying toe pressure to
the rudder pedals.
CAUTJON
Continuous brake application of either the
pilot's or copilot's brake. pedals in conjunction
whh an overriding pumping action from the op-
posite brake
pedals could result in the loss of
braking action
on the side which continuous
pressure is being applied.
The parking brake push-pull C:ontrol is located on the sub-
panel (right subpanel - C33, E33; left subpanel - F33). To
set the parking brakes, depress both toe pedals until firm.
then pul! contro! out. Push the control in to release the
brakes.
CAUTION
The parking brake should be left oft and wheei
chocks installed if the airplane is to be left
unattended. Changes in ambient temperature
can cause the brakes to release or to exert
excessive pressures.
MANUAL EXTENSION
The landing gear can be manually extended by operating a
handcrank
at the rear of the front seats. This procedure is
described in the EMERGENCY PROCEDURES section.
WARNING HORN
With the landing gear retracted, if the throttle is retarded
below approximately 12 in. Hg manifold pressure, a
warninE1 horn will sound intermittently.
August 1982
7-17
