SectionVll
Systems
Description
(CD-1027 thru CD-1254}
BEECHCRAFT
Debonair
C33
Bonanza E33 and F33
Fresh ram air from
the
air intake
on
the upper side
of
the
aft fuselage is ducted to individual outlets above each seat,
including the optional seat. Each outlet can be positioned
to direct the
flow
of
air
es
desired. The volume
of
in-
coming
air
can be regulated by rotating the outlet. A
system shutoff
valve is installed
in
the
duct
between the
overhead fresh air scoop and the individual fresh air
out-
lets. The valve is operated by a push-pull control in
the
overhead panel.
EXHA
UST
VENTS
(CD-814 thru CD-1199}
Air
is exhausted from the cabin through a fixed vent
below
the baggage compartment door
which
flows
to an exhaust
vent in the belly.
(CD-1027 thru CD-1254}
A manually controlled cabin air exhaust vent is located
aft
of the radio speaker
in
the overhead panel.
(CD-1200 thru CD-1254}
A fixed exhaust vent
is
provided through the rear
of
the
hat
shelf.
OXYGEN
SYSTEM
The oxygen cylinder is located beneath the cover under the
front
seats. The system is available
with
either
four
or
five
outlets and
with
either a
3B.
49
or
114
cu
ft
oxygen cyl-
inder. Supply of oxygen to the system is controlled by a
shut-off
valve on the oxygen console. The pressure gage
indicates the supply
of
oxygen available (
1850
psig is
nominal pressure for a
full
supply in the cylinder).
7-36
August
1982
