BEECHCRAFT
Debonair
Cll
Bonanza
EJJ
arid
fll
SectionVll
Systems
Description
The alternator field circuit breaker is located on the right
sub-panel and the alternator output circuit breaker is
in-
stalled on the
left
side of the nose wheel
weil
cover.
Refer to the
HANDLING, SERVICING AND MAINTENANCE
Section
for
minor
rnaintenance
ot
the alternator.
EXTERNAL
POWER
RECEPTACLE
The external power receptacle accepts a standard
AN
type
plug. Before connecting an external power
unit
turn
gen-
erator/altemator switch and avionic equiprnent
OFF.
CAUTION
A negative ground external power source is
required.
Check polaritv before using external
power.
lf
the external power
unit
does not have a Standard AN
type plug, connect the positive lead frqrn the external
power
source
to the positive battery terminal
and
the
negative lead to the negative battery terminal.
UGHTING
SYSTEM
·
INTERIOR
UGHTING
C33, E33
Lighting for the instrument panel is furnished by a
light
in
the cabin ceiiing. lt
is
controllEtd by the FLOOD LIGHTS
rheostat controi located
below
and to the right of the
control column.
A
RADIO and
POST
UGHTS control rheostat is located to
the left of the flood
light rheostat.
lt
controls the internal
lights
in
the radio installation end individual instrument
post
lights.
August
1982
7-29
