Bernette b79 - Page 108

Embroidering preparation
107
2019-02 EN 5020079.00A.04
> Remove the presser foot holder (2) by unscrewing the presser foot bar attaching screw (1).
2
1
> Attach the embroidery foot (JL) from the back with the index finger to the presser foot bar and tighten
the screw.
1
Mount the hopper embroidery foot
> Raise the needle.
> Raise the presser foot and dual feed.
> Switch the machine off and disconnect it from the power supply system.
> Remove the presser foot holder (2) by unscrewing the presser foot bar attaching screw (1).
2
1
> Mount the hopper embroidery foot (JX) on the presser foot rod, making sure that the spring (3) is above
the needle fixing screw (4).
> Tighten the screw (1).
4
3
1
