Embroidering preparation
108
2019-02 EN 5020079.00A.04
13.3 Needle and stitch plate
Inserting the embroidery needle
Embroidery needles of the type 130/705 H-SUK provide a larger eye and are slightly rounded. This avoids
thread abrasion when using Rayon- and cotton embroidery thread. Depending on the embroidery thread
use a size No. 70-SUK to No. 90-SUK needle.
> Raise the needle.
> Switch the machine off and disconnect it from the power supply system.
> Remove the attached foot.
> Loosen the needle clamp screw (1) using the screwdriver and remove the needle.
> Hold the needle with the flat side (2) to the back.
> Insert the needle as far up as it will go (3).
> Tighten the needle clamp (1) screw using the screwdriver.
Attaching the stitch plate (CutWork/Straight)
The Straight-/CutWork stitch plate has a small needle hole in the needle insertion area. The small needle hole
supports the fabric. This optimizes the stitching results.
> Switch the machine off and disconnect it from the power supply system.
> Remove the needle.
> Remove the presser foot.
> Lower the feed dog and remove the bobbin cover.
> Remove the screws of the stitch plate with a screwdriver.
> Remove the stitch plate.
