Bernette b79 - Second Spool Pin; Free Arm

Sewing preparation
28
2019-02 EN 5020079.00A.04
Second spool pin
Installing the second spool pin
The second spool pin is necessary when several threads are sewn.
> Insert the second spool pin onto the end of the bobbin winding unit(1).
> Align the notch (2) with the spring (3) on the bobbin winding unit.
1
2
3
Inserting thread spool
The felt disc prevents the thread from getting hooked at the second spool pin.
> Place the felt disc (1) on the second spool pin.
> Place the thread spool on the second spool pin.
1
2.3 Free arm
The bernette b79 provides a solidly designed free arm which offers a lot of space for large project on the
right of the needle.
