Stitch Designer
97
2019-02 EN 5020079.00A.04
> If a stitch design ends with reverse stitches or is a closed shape, a forward stitch must be inserted on the
same vertical axis as the first stitch so that the design can be sewn continuously.
– In the preview window in the left display portion it can be seen whether or not a stitch design is sewn
continuously.
> Touch the icon «Confirm».
– The stitch design is displayed and can be sewn.
– More than 3 mm of the line point will average allocate the next point distance automatically.
Creating stitch designs using screen dots
> Touch the icon «Grid on/off» to display the center of the hoop on the display.
– Every inserted point is automatically placed on the nearest grid point.
Free hand drawing
> Using the finger or the touchscreen pen, touch the stitch pattern view and draw a stitch design.
11.3 Editing the view
> Select a stitch pattern, alphabet or buttonhole.
> Touch the icon «Stitch Designer».
> Touch the icon «Zoom out» to minimize the view of the stitch pattern.
> Touch the icon «Zoom in» to enlarge the downsized stitch pattern view.
> Touch the icon «Move the view».
> Move the view of the stitch pattern using the touchscreen pen/finger.
11.4 Inserting points
A new point is inserted after a current position indicated by a white dot.
> Select a stitch pattern or alphabet.
> Touch the icon «Stitch Designer».
> Touch the icon «Engaging at the grid» to have the grid points displayed.
– Every inserted point is automatically placed on the nearest grid point.
> Touch the icon «Scroll up»/«Scroll down» to select the point.
> Touch the desired position in the «Stitch pattern view» with the touchscreen pen/finger.
– The new point is inserted after the selected point and can be moved to the desired position with the
multifunction knobs.
> Touch the icon «Back» to undo the last work step.
> Touch the icon «Redo» to restore the last work step.
