Sewing preparation
31
2019-02 EN 5020079.00A.04
Attaching the presser foot sole
> Raise the presser foot (1).
> Place the presser foot sole (2) under the shaft groove (3) so that the shaft groove is above the presser
foot sole pin (4).
> Then push the new presser foot sole upward until it engages.
3
2
4
1
Removing and inserting the presser foot holder
> Raise the presser foot.
> Align the presser foot holder (1) with the lower left side of the presser bar (2).
> Hold the presser foot holder and drive the screw in manually.
> Tighten the screw using the screwdriver.
1
2
Inserting the edge/ quilting guide
The edge/ quilting guide supports sewing parallel lines.
> Insert the edge/ quilting guide (1) in the slot (2).
> Adjust the width as desired.
2
1
