My BERNINA
24
Illustration Name Purpose
Soft Cover with pocket The soft cover protects the machine from dust and
contamination.
Accessory box The accessory box serves the purpose to store the
supplied accessories as well as the optional
accessories.
Knee lifter The presser foot may be raised and lowered with
the Free Hand System.
Slide-on table The slide-on table increases the sewing surface
whereby the area of the free arm is not limited.
Seam guide for slide-on
table
The seam guide is a useful when topstitching.
Straight/Cutwork stitch
plate
A small stitch hole in the area of the needle allows
an optimized stitch entry. This results in a nicer
stitch formation for 9.0 mm fabric feed.
3 Spool discs Spool discs hold the thread spool in place for
proper release of thread from the spool.
4 Bobbins in the
accessory, whereby 1
bobbin is already in the
bobbin case
The bobbins are filled with the lower thread.
2 Foam pads The foam pad prevents the thread from getting
hooked at the spool holder.
