Chapter 15 Technical Drawings
Mini-Switch LB 471
127
Super Sens with lateral irradiation 90°
Type
ATEX
Irradiation
Weight
in kg approx.
LB 4431-04-0s-Gd-E
Gas Ex
II 2 G EEx de IIC T6
90°
60
LB 4431-04-0s-Gi-E
Gas Ex
intrinsically safe
II 2 G EEx ib d IIC T6
90°
60
LB 4431-04-1s-Md-E
Firedamp
90°
60
LB 4431-04-1s-Mi-E
Firedamp intrinsically safe
90°
60
M16 for cable 5 … 10 mm
M16 for cable 5 … 10 mm
Specifications in mm
