BERTHOLD TECHNOLOGIES LB4710-080 - Page 25

Chapter 3 Functional Safety
Mini-Switch LB 471
25
Code
no.
Designation
Value range
Factory
setting
Value
Order
00
Password
0000 - 9999
01
Year
1970 - 2099
Current
year
1
02
Month / Day
01.01-12.31
Current
date
2
03
Hour / Minute
00.00-23.59
Current
time
4
04
Operation mode
Standard/Professional
0 - 1
0
1
3
05
Detector code
0 - 99
99
5
06
Nuclide
0=Co60, 1=Cs-137
0 - 1
0
6
07
Automatic password
protection
0 - 9999
0
08
Warning relay as
second alarm relay
0 – 1
10 – 100
0
09
Alarm relay follows
the error relay
0 - 1
0
1
7
10
Reading (%)
-999 - 9999
Display
11
Average count rate
0 - 999.9
Display
12
Time constant (s)
0,1 – 999,9
-1
13
Live count rate
0 - 999.9
Display
14
Maximum time constant (s)
0 - 999
999
8
15
Standard reading
10 - 11
10
16
Max. or min. limit
value switch
0=Max, 1=Min
0 - 1
0
17
Switching threshold (%)
0 - 100
-1
18
Switching threshold in (cps)
0 - 999.9
-1
19
Hysteresis (%)
0 - 999
-1
20
Empty count rate (no input)
0 - 999.9
Display
21
Full count rate (no input)
0 - 999.9
Display
22
Zero count rate (no input)
0 - 9.999
Display
30
Empty count rate
0 - 999.9
20 GMZ
300 FSK
31
Full count rate
0 - 999.9
-1
32
Zero count rate
0 - 9.999
Depending
on detector
code
33
Measuring path (in mm)
0 - 9999
0
9
34
Gas density (kg/m³)
0 - 9999
0
10
35
Bulk density (kg/m³)
0 - 9999
0
11
36
Compute
35.01–35.08
Display
37
Counting time for
calibration (s)
5 - 600
60
12
38
Bulk cone diameter (mm)
0 - 9999
0
Table 1:
Code table
for professional mode
