Code
no.
Designation
Value range
Factory
setting
Value
Order
39
Half-value layers
1 - 9
2
13
40
Interference radiation
detection
0 - 1
0
1
14
41
Waiting time after
interference radiation
0 - 999
20
15
42
Signaling interference
radiation
0 - 2
0
1
16
43
Signaling unlocked
0 - 2
0
1
17
44
Signaling minor errors
0 - 2
0
1
18
45
Signaling excess temp.
Detector (only FSK detector)
0 - 2
0
0
46
Temperature threshold
detector (only FSK)
0 - 99
40
47
Signaling excess temp.
EVU
0 - 2
0
1
19
48
Temperature threshold EVU
0 - 99
85
≤50
20
50
Limit switch software
1.00 - 9.99
Version
51
Detector software
(only FSK)
1.00 - 9.99
Display
52
Detector temperature °C
(only FSK detector)
-40 - 80
Display
53
Detector high voltage
(only FSK)
500 - 1300
-1
54
detector HV start value
(only FSK)
500 - 1300
HV default
55
Source replacement
00.00- 99.12
-1
56
Evaluation unit electronics
temperature
-100 - 200
Display
60
Test pulse generator
0 - 999.9
0
61
Test error relay
0 - 2
0
62
Test alarm relay
0 - 2
0
63
Test warning relay
0 - 2
0
64
Test display
65
Test keyboard
66
Status digital in
00.00 - 01.01
Display
67
HV max for plateau
measurement
500 - 1300
1000
68
Detector plateau
measurement
(only FSK)
0 - 5
0
70
Error log
0 - 1
0
71
Revision log
0 - 1
0
72
Save & Load / Reset
0 - 99
0
