22
*USB control requires installing USB
drivers first. Download USB driver
from
www.bkprecision.com
*USB interface is a virtual COM port. The settings are:
Baudrate : 57600 bps
Data bit : 8
Parity check : none
Stop bit : 1
*When entering the Remote mode, the screen will present RMT indicator
as shown in the following picture.
Set up GPIB ADDRESS (1-30)
HOT KEY:
This enables/disables the hot key function,
which allows you to quickly recall
instrument settings that are stored into
internal memory
locations. The “HOT”
indicator will be displayed when hot key is
enabled. Press any numeric keys 0 –
9 to
instantly recall the voltage/current settings
from the corresponding memory location.
BEEP:
Turns the Buzzer ON/OFF
LCD BACKLIT:
Set the
backlight of the LCD to Always
ON or OFF after 1/5/10/30 minutes
.=
.
.
=
.
FF
1 1
